Arranged by Microcontroller I/O Port Name and Bit Number
PIC32
Pin #
Connector
Pin #
Digital
Pin #
MCU
Port
Bit
PIC32 Signal Name
Notes
16
JC-07
20
RB00
PGED1/PMA6/AN0/VREF+/CVREF+/CN2/RB0 A2
15
JC-08
21
RB01
PGC1/AN1/VREF-/CVREF-/CN3/RB1
A3
14
JD-01
24
RB02
C2IN-/AN2/SS1/CN4/RB2
A4
13
JE-10
39
RB03
C2IN+/AN3/CN5/RB3
A10
12
JE-09
38
RB04
C1IN-/AN4/CN6/RB4
A9
11
JE-08
37
RB05
C1IN+/AN5/CN7/RB5
A8
17
N/A
N/A
RB06
PGEC2/AN8/OCFA/RB6
18
N/A
N/A
RB07
PGED2/AN7/RB7
21
JC-01
16
RB08
U2CTS/C1OUT/AN8/RB8
A0
22
JD-04
27
RB09
PMA7/C2OUT/AN9/RB9
A5
23
N/C
N/C
RB10
TMS/CVREFOUT/PMA13/AN10/RB10
24
N/C
N/C
RB11
TDO/PMA12/AN11/RB11
27
JD-07
28
RB12
TCK/PMA11/AN12/RB12
A6
28
JD-10
31
RB13
TDI/PMA10/AN13/RB13
A7
29
JC-04
19
RB14
PMALH/PMA1/U2RTS/AN14/RB14
A1
30
N/C
N/C
RB15
PMALL/PMA0/AN15/OCFB/CN12/RB15
39
N/A
N/A
RC12
OSC1/CLKI/RC12
X1, system clock
oscillator
47
N/A
N/A
RC13
SOSCI/CN1/RC13
X2, secondary oscillator
48
N/A
N/A
RC14
SOSCO/T1CK/CN0/RC14
X2, secondary oscillator
40
N/A
N/A
RC15
OSC2/CLKO/RC15
X1, system clock
oscillator
46
JC-09
22
RD00
OC1/RD0
PIN_OC1
49
JC-10
23
RD01
OC2/RD1
PIN_OC2
50
JD-02
25
RD02
OC3/RD2
PIN_OC3
51
JD-08
29
RD03
OC4/RD3
PIN_OC4
52
JB-09
14
RD04
PMWR/OC5/IC5/CN13/RD4
PIN_OC5
53
JB-08
13
RD05
PMRD/CN14/RD5
54
JB-07
12
RD06
CN15/RD6
55
JB-10
15
RD07
CN16/RD7
42
JE-07
36
RD08
IC1/RTCC/INT1/RD8
43
JB-01
8
RD09
IC2/U1CTS/INT2/RD9
44
JD-03
26
RD10
IC3/PMCS2/PMA15/INT3/RD10
45
JD-09
30
RD11
IC4/PMCS1/PMA14/INT4/RD11
60
JA-01
0
RE00
PMD0/RE0
61
JA-02
1
RE01
PMD1/RE1
62
JA-03
2
RE02
PMD2/RE2
63
JA-04
3
RE03
PMD3/RE3
64
JA-07
4
RE04
PMD4/RE4
