Cerebot MC7 Reference Manual

www.digilentinc.com

page 15 of 21

Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.

MCU Pin to Pmod Connector Pin

MCU Pin

MCU
Port Bit

Connector
Pin

Signal

Notes

1

RE05

N/A

PWM3H,RE5

PWM3H, half bridge 3 high side

2

RE06

N/A

PWM4L/RE6

PWM4L, half bridge 4 low side

3

RE07

N/A

PWM4H/RE7

PWM4H, half bridge 4 high side

4

RG06

JB-04

SCK2/CN8/RG6

SPI #2

5

RG07

JB-03

SDI2/CN9/RG7

SPI #2, Selectable via JP2

6

RG08

JB-02

SDO2/CN10/RG8

SPI #2, Selectable via JP3

7

N/A

MCLR

on-board program/debug circuit

8

RG09

JB-01

SS2/CN11/RG9

SPI #2

9

N/A

VSS

10

N/A

VDD

11

RB05

N/A

AN5/QEB/IC8/CN7/RB5

motor 1, quadrature encoder input

12

RB04

N/A

AN4/QEA/IC7/CN6/RB4

motor 1, quadrature encoder input

13

RB03

N/A

AN3/INDX/CN5/RB3

half bridge 4 current sense

14

RB02

N/A

AN2/SS1/CN4/RB2

half bridge 3 current sense

15

RB01

N/A

PGEC3/AN1/VREF-/CN3/RB1

half bridge 2 current sense

16

RB00

N/A

PGED3/AN0/VREF+/CN2/RB0

half bridge 1 current sense

17

RB06

N/A

PGEC1/AN6/OCFA/RB6

on-board program/debug circuit

18

RB07

N/A

PGED1/AN7/RB7

on-board program/debug circuit

19

N/A

AVDD

20

N/A

AVSS

21

RB08

U2CTS/AN8/RB8

BTN1

22

RB09

N/C

AN9/RB9

23

RB10

N/A

TMS/AN10/RB10

half bridge 1, voltage sense

24

RB11

N/A

TDO/AN11/RB11

half bridge 2, voltage sense

25

N/A

VSS

26

N/A

VDD

27

RB12

N/A

TCK/AN12/RB12

half bridge 3, voltage sense

28

RB13

N/A

TDI/AN13/RB13

half bridge 4, voltage sense

29

RB14

JB-09

U2RTS/AN14/RB14

shared with BTN2

30

RB15

JB-10

AN15/OCFB/CN12/RB15

31

RF04

N/A

U2RX/SDA2/CN17/RF4

I2C Bus #2, not shared with Pmod
connector

32

RF05

N/A

U2TX/SCL2/CN18/RF5

I2C Bus #2, not shared with Pmod
connector

33

RF03

JA-02

U1TX/SDO1/RF3

UART #1 TX

34

RF02

JA-03

U1RX/SDI1/RF2

UART #1 RX

35

RF06

JA-04

U1RTS/SCK1/INT0/RF6

UART #1

36

RG03

N/A

SDA1/RG3

I2C Bus #1, not shared with Pmod
connector

37

RG02

N/A

SCL1/RG2

I2C Bus #1, not shared with Pmod
connector

38

N/A

VDD

39

RC12

N/A

OSC1/CLKIN/RC12

crystal connection

40

RC15

N/A

OSC2/CLKO/RC15

crystal connection

41

N/A

VSS

42

RD08

N/A

IC1/FLTA/INT1/RD8

bridge over-current detect

43

RD09

JA-01

IC2/U1CTS/FLTB/INT2/RD9

UART #1

44

RD10

JB-07

IC3/INT3/RD10

45

RD11

JB-08

IC4/INT4/RD11
