RocketLinx ES8510-XTE User Guide: 2000574 Rev. C Feature Overview - 41
Configuration Using the Web User Interface
Port Statistics
Port Statistics on
Page 117
Port by Port
• Type
• Link
• State
• Rx and Tx Good
• Rx and Tx Bad
• Rx Abort
• Collision
Port Status
Port Status on
Page 66
• Port Type
• Link - Up/Down
• State - Enable/Disable
• Speed/Duplex
• Flow Control
• SFP Vendor, Wavelength, and Distance
• SFP DDM - Temperature, Tx Power, and Rx Power
Port Trunk
Aggregation
Setting
on Page 68
Aggregation Status
on Page 69
Aggregation Settings
• Group ID - Trunk 1-5
Trunk Type - Static or 802.3ad LACPAggregation Status by
Trunk
• Type
• Aggregated Ports
• Individual Ports
• Link down Ports
PVLAN
Configuration
PVLAN
Configuration
on
Page 91
• VLAN ID
• PVLAN Type - None, Primary, Isolated, and Community
PVLAN Information
PVLAN
Information
on
Page 93
• Primary VLAN
• Secondary VLAN
• Secondary VLAN Type
• Ports
PVLAN Port
Configuration
PVLAN Port
Configuration
on
Page 92
Port Configuration
• PVLAN Port Type - Normal, Host, or Promiscuous
• VLAN ID
PVLAN Association
• Secondary VLAN
• Primary VLAN
Type Category Details
