150 - Network Redundancy (CLI) RocketLinx ES8510-XTE User Guide: 2000574 Rev. C
Configuration Using the Command Line Interface (CLI)
GLobal (STP, RSTP, and MSTP) (cont.)
Forward Delay
Switch(config)# spanning-tree forward-time
<4-30> the value of forward delay time in seconds
Switch(config)# spanning-tree forward-time 15
Max Age
Switch(config)# spanning-tree max-age
<6-40> the value of message maximum age time in seconds
Switch(config)# spanning-tree max-age 20
Hello Time
Switch(config)# spanning-tree hello-time
<1-10> the value of hello time in seconds
Switch(config)# spanning-tree hello-time 2
MSTP
Enter the MSTP
Configuration
Tree
Switch(config)# spanning-tree mst
MSTMAP the mst instance number or range
configuration enter mst configuration mode
forward-time the forward delay time
hello-time the hello time
max-age the message maximum age time
max-hops the maximum hops
sync sync port state of exist vlan entry
Switch(config)# spanning-tree mst configuration
Switch(config)# spanning-tree mst configuration
Switch(config-mst)#
abort exit current mode and discard all changes
end exit current mode, change to enable mode and apply all changes
exit exit current mode and apply all changes
instance the mst instance
list Print command list
name the name of mst region
no Negate a command or set its defaults
quit exit current mode and apply all changes
revision the revision of mst region
show show mst configuration
Region
Configuration
Region Name:
Switch(config-mst)# name
NAME the name string
Switch(config-mst)# name comtrol
Region Revision:
Switch(config-mst)# revision
<0-65535> the value of revision
Switch(config-mst)# revision 65535
Mapping
Instance to
VLAN (Ex:
Mapping VLAN
2 to Instance 1)
Switch(config-mst)# instance
<1-15> target instance number
Switch(config-mst)# instance 1 vlan
VLANMAP target vlan number(ex.10) or range(ex.1-10)
Switch(config-mst)# instance 1 vlan 2
