1G70VR/10BCWR (En/KJ
AUDIO section
Rated power output during STEREO operation
(1070VR)
izu watts per channel minimum KMS, both channeis
driven, at 8 Q from 20 Hz to 20 kHz with nomorethan
0.06 % totai harmonic distortion.(FTC)
I1060VR)
110 watts per channel minimum RMS, both channeis
driven,at 8Qfrom20Hzto20kHzwithnomorethan
0.06 "/e total harmonic distortion.(FTC)
Rated power output during SURROUND operation
(1070VR)
FRONT
(1kHz, 0.7% T.H.D. at 8 a)................................ 120 W+ 120 W
CENTER
(1kHz, 0.7% T.H.D. at 8 a)................................................. 120 W
SURROUND
(1kHz, 0.7% T.H.D. at 8 ii).....................................60 W + 60 W
(1060VR)
FRONT
(1kHz, 0.7% T.H.D. at 8 0) .................... ............ 1 1 0 W + H O W
CENTER
(1kHz, 0.7% T.H.D. at 8 O)...................
....................... n o w
SURROUND
(1kHz, 0.7% T.H.D. at 8
0)..................... ....................... n o w
Total harmonic distortion
I1070VR)...........................................0.015%(1 kHz, 60W, 8 Q)
I1060VR)...........................................0.015%(1 kHz, 55W, 8 Q)
Frequency response
CD ........................................... 5 Hz ~ 86 kHz, +0.6 dB, -3 dB
Signal to noise ratio (IHF'66)
PHONO (MM)........................................................................75 dB
CD..........................................................................................95 dB
Input sensitivity / impedance
PHONO (MM)........................................................2.5 mV / 47 kQ
CD........................................................................ 200 mV / 47 k£i
ADAPTOR IN.......................................................400 mV / 10 kn
Output level / impedance
TAPE REC........................................................... 200 mV / 1 kn
ADAPTOR OUT............................................. 200 mV / 1 kn
PRE OUT [CENTER, SURROUND)......................... 1 V / 600 n
PRE OUT [SUBWOOFER) ........................................ 1 V / 1 kii
Tone control
BASS..............................................................±8 dB (at 100 Hz)
TREBLE......................................................... ±8 dB (at 10 kHz)
LOUDNESS control
VOLUME at -40dB level... +7 dBdOO Hz), +3 dB(10 kHz)
VIDEO section
VIDEO inputs / outputs
VIDEO (composite). . 1 Vp-p / 75 n
FM tuner section
Tuning frequency range............................... 87,5 MHz ~ 108 MHz
Usable sensitivity (MONO)
......l.epV (75 n)/ 15.2 dBt (75 kHz DEV., SINAD 30 dB)
50dB quieting sensitivity
STEREO............................................. 31.6pV (75 Q\l 41.2 dBf
Total harmonic distortion (1 kHz)
(tor U.S.A. and Canada)
MONO........................................................ 0.2 % (65 dBf input)
STEREO.................................................... 0.5 % (65 dBf input)
(except for U.S.A. and Canada)
MONO ....................................................... 0.6 % (65 dBf input)
STEREO.................................................... 0.7 % (65 dBf input)
Signal to noise ratio (1 kHz, 75 kHz DEV.)
MONO.......................................................75 dB (65 dBf input)
STEREO................................................... 68 dB (65 dBf input)
Stereo separation (1 kHz).......................................................... 40 dB
Selectivity (±400 kHz)
(for U.S.A. and Canada) ................................................... 70 dB
(except for U.S.A. and Canada)........................................50 dB
Frequency response.................30 Hz ~ 15kHz,+0.5 dB, -3.0 dB
AM tuner section
Tuning frequency range (for U.S.A. and Canada)
10 kHz step.............................................. 530 kHz - 1.700 kHz
Tuning frequency range (except for U.S.A. and Canada)
9 kHz step.................................................531 kHz ~ 1,602 kHz
10 kHz step.............................................. 530 kHz ~ 1,610 kHz
Usable sensitivity (30% mod., S/N 20 dB)
.................................................................. 16 pV / (600 pV/m)
Signal to noise ratio (30 % mod., 1 mV input).........................48 dB
GENERAL
Power consumption
(1070VR)................................................................................ 2.9 A
(1060VR)................................................................................ 2.5 A
AC outlet
SWITCHED................................ 2 (total 100 W, 0.83 A max.)
Dimensions...................................................... W : 440 mm (17-5/16")
.............................................................. H : 147 mm (5-13/16")
.............................................................. D : 392 mm (15-7/16")
Weight (Net)
(1070VR).............................................................. 11 kg (24.3 lb)
(1060VR).............................................................. 10 kg (22.0 lb)
KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice.
