1070VR/10BaVR (En/Kl
Connecting the system control
Connecting system control cords after connecting a KENWOOD audio component system lets you take advantage of
convenient system control operations.
There are two KENWOOD system control modes. Make connections according to the groups of terminal symbols shown
below.
CXSHl Mode : lets you uurnbirio [X£, IXSHI, and IXT" loiiriiiials
[H.IEI Mode : for SL1&) terminals only
Ttiis unit is compatible with both |XS8] and [SL161 modes. It comes from the factory set to the ISLl 6] mode. To switch to the [XSS] mode, follow
the ineti-uetions
in "GWITCl liNG mOM IGUC] TO IXSOI" below.
EXAMPLE: [XSS] mode connections
The underlined portion represents the setting of the system control mode.
EXAMPLE: [SL16] mode connections
The underlined portion represents the setting of the system control mode.
[SL161 IXS8]
[SL16]
[SL16HXSJ [XS8] [XR]
[SL16] [XS] rXS81
[XS]
Receiver
MD recorder
Cassette deck
CD player
n
SYSTEM
CONTROL
cord
Record player
n
ÌSL161 [XS8]
ÌSL161
ÌSL161 [XS] [XS8] [XR]
[SL161 [XS] [XS8]
[XS]
Receiver
MD recorder
Cassette decjk
CD player
SrSTEM
CONTROL
cord
Record player
• In order to take advantage of the system control operations, the components must be connected to the correct jacks. To use a CD player it must
be connected to the CD jacks. To use a cassette deck (or MD recorder} it must be connected to the TAPE/MD jacks. When using more than one
CD player (etc.) only the one connected to the specified jacks may be connected for system control.
' Some CD players and cassette decks are not compatible with the [SL16] system control mode. Be sure to use the [XS8I system control mode
when making system connections with equipment that is not [SL16] compatible,
• Some MD players are not system control compatible. You cannot nnake system control connections to this kind of equipment.
w
. [SL1GJ equipment cannot be combined with [XR], [XS], and [XSS] equipment for system operations. If your
equipment consists of this kind of combination, please do not connect any system control cords. Even without
system control cords, normai operations can be earned out without effecting performance.
. Do not connect system control cords to any components other than those specified by KENWOOD. It may
cause a malfunction and damage your equipment.
. Be sure the system control plugs are inserted aN the way in to the system control terminals.
SYSTEM CONTROL OPERATIONS
i
SWITCHING FROM [SLW] TO [XSS]
1
Remote Control
Lets you operate this unit with the system remote supplied with the
receiver.
i
You can easily change the system control mode by adjusting the
position of the SYSTEM CONTROL switch on the rear panel.
Do this operation after completing all connections.
Automatic Operation (except [XR] equipment)
When you start playback from a source component, the input selector
on this unit switches to that component automatically. '
ForlSLiei SL IB XS 8 ForjXSSI s
-------------1 1------------- H
an
i
Synchronized Recording (except EXR] equipment)
Lets you synchronize recording with the start of playback when
recording from CD, MD or analog discs.
i
Ì
• This operation wiil not effect items stored in the memory. ^
• After switching the system controi mode, turn the power off and '
then on once to confirm the new setting. j
Registering setup codes for KENWOOD audio components
* Once you finish making the system connections, be sure to register the appropriate setup code for each component.
► If you own remote controllable KENWOOD audio components that are not compatible with system control (or cannot be combined with your other
system control components), registering the setup code enables you to control those components using the remote control supplied with this
unit (without connecting system control cords). To register setup codes for your remote controllable KENWOOD audio components, see
"Registering setup codes for other components".
