DIGITAL-LOGIC AG SMA200 Manual V1.0
40
6.
SMART
C
ORE
-E
XPRESS
C
ONNECTOR
S
PECIFICATIONS
The connector type is equal to the COMexpress connector. This is a 220pin, surface-mounted connector
with 0.5mm pitch.
Parameter Condition Specification
Contact Copper alloy Material
Housing Thermoplast molded compound LCP
Current 0.5 Amp
Voltage 50 VAC
Termination Resistance 55mΩ max. ∆R = 20mΩ max.
Electrical
Insulation Resistance 500MΩ
Mating Cycles 30
Connector Mating Force 0.9N per contact
Connector Un-mating Force 0.1N per contact
Pitch 0.5mm
Number of pins 220
Mechanical
Temperature rating -40°C to 85°C
The manufacturer of the connector is:
Source on smartCore Part Name Part Number
Carrier Board Connector
TYCO / AMP H = 8mm Alternative
H = 5mm Standard 8-6318491-6
3-1827253-6
smartCoreExpress Module Connector
TYCO / AMP Mating connector 8-1318490-6
The stack height may be defined on the carrier board as either 5 or 8mm using the two different connector
types available.
