DIGITAL-LOGIC AG SMA200 Manual V1.0
13
Intel US15W
Specification
PCIe BUS 2x x1 Lane
EIDE BUS 1x Ultra P-ATA 100
SATA BUS -
USB V2.0 8 channel USB
APIC INTEL I/O APIC
SMB V2.0 SMBus controller
FWH FirmWare Hub for BIOS devices
LPC Serialized BUS (no ISA) used for external SuperI/O
Sound AC97 2.3 HDA Interface with 192kHz sampling rate and 8 channels
IRQ Controller 8259 compatible
Timers 8254 compatible
Power Management Integrated
Reset & Power Management Specification
Controller Atmel
Power Modes S5, S3
ACPI V3.0
BUS Specification
LPC 8bit 33MHz
PCIexpress 2x x1 lane
Power Supply Specification
DC Input 5.0V, max. 200mV ripple
Inrush Current 5.0V up to 2Amp for 100µs
Standby Power 0.1W
Onboard Voltages VCC Core, 1.05V, 1.8V, 0.9V, CoreVCC, 1.5V
Power Consumption 4W
Use inductors in series to reduce the maximum inrush current!
Physical Characteristics Specification
Dimensions Length: 65 mm +/- 0.1mm
Depth: 58 mm +/- 0.1mm
Height: 11 mm +/- 0.2mm (with 5mm bus connectors)
14 mm +/- 0.2mm (with 8mm bus connectors)
The connector height is selected by the connector on the carrier board.
Weight 70 gr / 8 ounces
PCB Thickness 1.6 mm / 0.0625 inches nominal
PCB Layer Multilayer
