DIGITAL-LOGIC AG SMA200 Manual V1.0
12
2.2. Technical Specifications
CPU Specification
CoreDuo / Celeron M Intel Atom 510 1.10GHz with 0.5MB L2-cache
Intel Atom 530 1.60GHz with 0.5MB L2-cache
Clock 1.1 or 1.6GHz
1
st
Level Cache 2x 32kByte
2
nd
Level Cache 0.54 MByte (on die)
Technology 40nm
VCCCore @ 1.6GHz 1.050V
VCCCore @ 1.1GHz 0.844V
VCCCore @ deep sleep 0.748V
CPU BUS CMOS
AGTL+ Termination Not needed
FSB 533MHz quad-pumped synchronous BUS
Mathematics Coprocessor
Available on the Atom CPU
Intel US15W Graphics Memory Controller Hub
Memory Controller
Specification
Supports
Socket DDR2 soldered memory
Technologies DDR2-667
Capacity 512MByte up to 2GByte
Voltage 1.8V
Termination 0.9V
Width 64bit
ECC-Support No
Intel US15W Graphics Memory Controller Hub
Graphic Controller
Specification
Max. Video Memory 128MByte with Intel GMA
Graphic Core Frequency 250MHz
SDVO Port 2 channels (multiplexed with the PEG signals)
1x 200 Mpixel/sec
Support for up to 1x DVI, 1x VGA and 1x LVDS
Dotclock = 165MHz
Compliant with DVI Spec.1.5
Flat Panel Interface 2 channel LVDS interface
1x 18, 2x 18, 1x 24, 2x 24bpp TFT
Dotclock = up to 2x 112 MHz
Resolutions 640 x 480 up to 1600 x 1200 (UXGA)
Automatic panel detection via VESA EDID 1.3
LVDS 24bit 200Mpixel/sec
