4.2. smartCoreExpress Connector Pinout
BUS on the smartCoreExpress – Connectors A / B: Pins 1-55
Pin Signal BUS Type Remarks Pin Signal BUS Type Remarks
A1 GND B1 GND
A2 PCIe_TX0_N PCIe Dif AC B2 PCIe_RX0_N PCIe Dif AC
A3 PCIe_TX0_P PCIe Dif AC B3 PCIe_RX0_P PCIe Dif AC
A4 PCIe_CLK0_N PCIe Dif AC B4 PCIe_CLK1_N PCIe Dif AC
A5 PCIe_CLK0_P PCIe Dif AC B5 PCIe_CLK1_P PCIe Dif AC
A6 GND B6 GND
A7 PCIe_TX1_N PCIe Dif AC B7 PCIe_RX1_N PCIe Dif AC
A8 PCIe_TX1_P PCIe Dif AC B8 PCIe_RX1_P PCIe Dif AC
A9 PCIe_TX2_N PCIe Dif AC B9 PCIe_RX2_N PCIe Dif AC
A10 PCIe_TX2_P PCIe Dif AC B10 PCIe_RX2_P PCIe Dif AC
A11 GND B11 GND
A12 PCIe_CLK2_N PCIe Dif AC B12 PCIe_CLK3_N PCIe Dif AC
A13 PCIe_CLK2_P PCIe Dif AC B13 PCIe_CLK3_P PCIe Dif AC
A14 PCIe_TX3_N PCIe Dif AC B14 PCIe_RX3_N PCIe Dif AC
A15 PCIe_TX3_P PCIe Dif AC B15 PCIe_RX3_P PCIe Dif AC
A16 GND B16 GND
A17 PCIe_REQ0# PCIe 3.3v-O Clk request B17 PCIe_REQ1# PCIe 3.3v-O Clock request
A18 PCIe_REQ2# PCIe 3.3v-O Clk request B18 PCIe_REQ3# PCIe 3.3v-O Clock request
A19 SDVO_CLK_N SDVO Dif AC B19 SDVO_INT_N SDVO Dif AC
A20 SDVO_CLK_P SDVO Dif AC B20 SDVO_INT_P SDVO Dif AC
A21 GND B21 GND
A22 SDVO_GREEN_N SDVO Dif AC B22 SDVO_BLUE_N SDVO Dif AC
A23 SDVO_GREEN_P SDVO Dif AC B23 SDVO_BLUE_P SDVO Dif AC
A24 SDVO_TVCLK_N SDVO Dif AC B24 SDVO_STALL_N SDVO Dif AC
A25 SDVO_TVCLK_P SDVO Dif AC B25 SDVO_STALL_P SDVO Dif AC
A26 GND B26 GND
A27 SDVO_RED_N SDVO Dif AC B27 SDVO_DDC_CLK SDVO 3.3V Bidir.
A28 SDVO_RED_P SDVO Dif AC B28 SDVO_DDC_DAT SDVO 3.3V Bidir.
A29 LVDS_D0_P LVDS Dif LV B29 LVDS_D1_P LVDS Dif LV
A30 LVDS_D0_N LVDS Dif LV B30 LVDS_D1_N LVDS Dif LV
A31 GND B31 GND
A32 LVDS_D2_P LVDS Dif LV B32 LVDS_CLK_P LVDS Dif LV
A33 LVDS_D2_N LVDS Dif LV B33 LVDS_CLK_N LVDS Dif LV
A34 LVDS_D3_P LVDS Dif LV B34 LVDS_BKL_CTR LVDS 3.3v
A35 LVDS_D3_N LVDS Dif LV B35 LVDS_BKL_EN LVDS 3.3v
A36 GND B36 LVDS_DETECT# LVDS 3.3V
A37 LVDS_DDC_DAT LVDS 3.3v B37 LVDS_VDD_EN LVDS 3.3V
A38 LVDS_DDC_CLK LVDS 3.3v B38 USB_C_DEV USB 3.3V
A39 USB_0_P USB Dif LV B39 USB_1_P USB Dif LV
A40 USB_0_N USB Dif LV B40 USB_1_N USB Dif LV
A41 GND B41 GND
A42 USB_2_P USB Dif LV B42 USB_3_P USB Dif LV
A43 USB_2_N USB Dif LV B43 USB_3_N USB Dif LV
A44 USB_4_P USB Dif LV B44 USB_5_P USB Dif LV
A45 USB_4_N USB Dif LV B45 USB_5_N USB Dif LV
A46 GND B46 GND
A47 USB_6_P USB Dif LV B47 USB_7_P USB Dif LV
A48 USB_6_N USB Dif LV B48 USB_7_N USB Dif LV
A49 USB_OC01# USB 3.3v B49 USB_OC23# USB 3.3v
A50 USB_OC45# USB 3.3v B50 USB_OC67# USB 3.3v
A51 GND B51 GND
A52 GE_CLK GE-LAN B52 GE_RTS GE-LAN
A53 GE_TX0 GE-LAN B53 GE_RX0 GE-LAN
A54 GE_TX1 GE-LAN B54 GE_RX1 GE-LAN
A55 GE_TX2 GE-LAN B55 GE_RX2 GE-LAN
