O Strip coating. O Loosen. © Insert. O Secure.
• Never short circuit the + and - speaker cords.
• If the left and right speakers are connected inversely on
speaker cords are connected with reversed polarityf
sound will be unnatural with annbiguous acoustic imagl
Be sure to connect the speakers correctly.
• To emphasize deep bass sounds, connect a sub-woofer as
desired.
%
©
i
[HI spu I^ fis [D
(8-1 BO)
Ì
oU
Use the FRONT SPEAKERS SYSTEM B terminals if you want
to connect a second front speaker system.
Powered
sub-woofer
Left Rear Speakers
(8£2~16i2)
(Be sure to connect both rear speakers)
Connection of banana plugs (ForU.S.A. and Caaada only)
O Secure. © Insert.
• Sound will not be heard if the
speaker terminal is not fully
secured.
Setting the FRONT SPEAKERS IMPEDANCE SELECTOR
When using FRONT SPEAKERS A and B separately.
Speaker impedance Selector position
40,60 B4
80, 160 Bt
When using FRONT SPEAKERS A and B at the same time
CAUTION: TO PREVENT FIRE, OR DAMAGE TO THE RECEIVER,
SET THE IMPEDANCE SELECTOR SWITCH AS DE­
SCRIBED BELOW.
Set the IMPEDANCE SELECTOR on the rear panel of the receiver
according to the impedance of the speakers you plan to use.
Speaker impedance Selector position
80, 160
•When the IMPEDANCE SELECTOR switch is set to “A op B :LESS
THAN 8D, A and B : 8Q OR MORE”, it is possible to use the A a^
B speakers at the same time.
Therefore, when using the speakers A and B simultaneously, be
to set the IMPEDANCE SELECTOR switch to the A or B :LESS THi
80, A and B : 80 OR MORE" position.
• Set the MAIN POWER key to the OFF position when connecting
speakers or adjusting the IMPEDANCE SELECTOR.
