Small Office Remote Access Switch 97
A PPLE T ALK R OUTING N ETWORK
Initial Installation Steps
Device Name: SITE2
Calling (ISDN, FR, etc.) Information X.25 Information
Authentication Information : Frame Relay Information
* HDLC Bridge only
Protocol for this particular device?
Bridge IP
IPX AppleTalk
Line Protocol PPP PVC
Base Data Rate 64000 bps SVC
Initial Data Rate 64000 bps
Max Data Rate 384000 bps
Dial-Out Number(s) 913135553232
PAP Password DLCI
CHAP Secret hcaz
IP Host ID
Bridge Ethernet Address*
Bridge Password*
CLID(s)
Bridging enabled? ❒ enabled ❒ disabled IP enabled? ❒ enabled ❒ disabled
Make calls
for bridged data? ❒ enabled ❒ disabled IP Address
(on WAN link)
For IP RLAN, IP (Sub-)
network number ❒ 0.0.0.0 if
unnumbered link
For IPX RLAN, external
network number Make calls for IP data? ❒ enabled ❒ disabled
IPX enabled? ❒ enabled ❒ disabled AppleTalk enabled? X enabled ❒ disabled
Callable by IPX? ❒ enabled ❒ disabled AppleTalk Address 0.0
IPXWAN protocol? ❒ enabled ❒ disabled Make calls for
AT data? X enabled ❒ disabled
IPX routing protocol?
❒ none
❒ RIP/SAP
❒ triggered RIP/SAP
AT Routing Protocol none
IPX spoofing?
