Isdn, Site: san fran – Cabletron Systems 150 User Manual
Page 29
Small Office Remote Access Switch 29
IP R
OUTING
N
ETWORK
Initial Installation Steps
File Server
BRI
PC
BRI
128.1.1.1
192.1.1.2
Rick Bear
ISDN
LAN 131.1.0.0
Router 1
131.1.1.16
128.1.1.16
WAN Interface 192.1.1.1
Host
SITE:
San Fran
BRI
128.1.1.3
Todd Jones
Host
BRI
192.1.1.3
Victoria Moose
Host
BRI
128.1.1.2
Jill Smith
Host
N
ETWORK
T
OPOLOGY
