EXAMPLE NETWORKS
50 CyberSWITCH
B RIDGING
IP R OUTING
Network Interface Information
Static Routes
Bridging ❒ enabled X disabled
Mode of Operation ❒ restricted ❒ unrestricted
Bridge Filters
Bridge Dial Out/
Known Connect List
IP Routing X enabled ❒ disabled
Mode of Operation X router ❒ IP host
LAN Name CorpOffice
IP address 128.1.1.1
Mask 255.255.0.0
Unnumbered WAN ❒ need
❒ don’t need
Remote LAN Name Satellites
IP address 198.12.10.1
Mask 255.255.255.0
Traditional WAN Name
IP address
Mask
Direct Host WAN Name
IP address
Mask
IP Host Mode IP address
Mask
Destination network address Mask Next hop
❒ default?
❒ default?
❒ default?
❒ default?
B RIDGING AND R OUTING I NFORMATION
