INT9 A/D converter
4 Using the INT9 card
Note:
Synchronize Start with Digital Input reflects the settings of the Contact
Closure/Opening of the External Start/Stop option in the
dialog.
Device Setup
This section allows to modify the naming of digital inputs and outputs and
change the mains Supply Frequency Suppression settings.
Digital Input Names
Allows to change the names of digital inputs.
Fig 11: Digital Input Names
Digital Output Names
Allows to change the names of digital outputs. These names will be
used in the
Digital Output Control
dialog in the chapter "Digital Inputs
Fig 12: Digital Output Names
Supply Frequency
Allows to change the mains Supply Frequency Suppression. It is used
for suppressing the interference on the specified frequency level. This
setting influences the sampling frequency as well.
