Whirlpool 3ET16NKXDG00 - Manual (Page 14)

To rolnstall sholf:
1. Hold shelf at front and back.
2. Tilt front of shelf up to a 45° angle to track.
3. Insert both rear shelf slides into upper
channel of track.
4. Lower front of shelf to a level position.
NOTE: Make sure both rear shelf slides are
securely in the track before letting go of
shelf.
Insert rear shelf slides
Into upper channel of
track.
Upper channel
of track
Removing the meat drawer and cover
Style 1
To remove the meat drawer:
1. Slide meat drawer out to the stop.
2. Lift front of meat drawer and slide meat
drawer out the rest of the way.
3. Replace in reverse order.
To adjust the cover position:
1. TiK front of cover up.
2. Lift back of cover.
3. Pull cover straight out.
To replace the cover:
1. Guide the cover’s rear hooks into the
slots in the shelf supports on cabinet wall.
2. Tilt cover up at front until the hooks
drop into slots.
3. Lower front of cover to a level
position.
STYLE 1
Pull out to the stop, lift the front, and pull again.
13
