WI-FI ROUTER

DODGE RAM-QUAD CAB

PROCEDURE STEPS:

NOTE: Using a test light, verify the cigarette lighter outlet being used is ignition switched. Power must not be
supplied with the ignition in the OFF position.

NOTE: If equipped with the mini console, proceed to step 4. If equipped with a full console, proceed to step 11.

Disconnect and isolate the battery negative cable.

Using a trim stick C-4755 or equivalent, disengage the
retaining tabs and remove the lower bezel panel (2).

Remove the two lower screws (3) securing the cup
holder or close out panel (2) to the instrument panel
(IP).

Aug 08, 2008

K6860631Rev. 1
