1
WI-FI ROUTER
MINIVAN
PROCEDURE STEPS:
NOTE: Using a test light, verify the cigarette lighter outlet being used is ignition switched. Power must not be
present with the ignition in the OFF position.
1. Move the passenger seat to the full rearward position.
2. Disconnect the negative battery cable.
3. Remove the six fasteners (2) on both sides of the stor-
age bin.
4. Carefully disengage the two spring clips from the top
center of the bin and pull the storage bin towards the
rear of the vehicle.
5. Route the Wi-Fi power harness (1) under the carpet
from the passenger seat to the instrument panel stor-
age bin (2).
Aug 08, 2008 K6860631 Rev. 1
