21
Canopy Mounting.
Caution: Do not glue the canopy to the hatch
without the hatch mounted to the fuselage.
You can warp it and it will not fit back on
the fuselage.
1. Mount the hatch to the fuselage using the two
4-40 x 1/2” screws.
Put a piece of wax paper between the tur-
tledeck and canopy bulkhead to prevent glue
from getting in the seam.
2. Put a bead of canopy glue around the edge of
the canopy on the inside and fit into place.
Make sure canopy is properly positioned and
hold in place with masking tape till glue dries.
Most canopy glues can be cleaned up with
water while still wet.Remove any smudges
with a damp cloth.
wing bolt
2. Trial fit the wing tube into each wing panel.If
very tight try a little wax on the wing tube work
it in and out till it frees up.
Fit both wings in place and hold in place with
the 1/4-20 nylon bolts.
Note: The bolts are sent full length, you will prob-
ably want to cut them down to about 3/4” to
1” to make them easier to install.
3. Install the battery pack according to where you
need the weight to make the CG correct.
With all equipment installed, check the CG.
The CG should be 4-1/2” to 4-3/4” behind the lead-
ing edge of the wing at the fuselage side.
Control Throws and CG
Ailerons Low Rate 3/4” each direction
High Rate 1-1/2” each direction
Elevators Low Rate 1-1/4” each direction
High Rate 3” each direction
Rudder Low Rate 2” each direction
High Rate 4” each direction
CG Location 4-1/2”to 4-3/4” behind the
leading edge of the wing
next to the fuselage side.
wax paper
