18
7. Insert the pushrod into the ez-connector and
attach servo arm to servo.
Move the throttle servo to full throttle, move
engine throttle arm to full throttle and tighten
the screw on top of ez-connector.
Cut off excess pushrod.
Fuel Tank Installation
1. Collect the following items:
(1) fuel tank
(1) cap assembly
(1) clunk
(1) pick up tube
(3) aluminum tubes
2. Insert the three aluminum tubes into the cap
assembly.
There should be two short tubes that extend out
the front and back of the cap about 1/2” to
5/8”. The third line is the vent and should
be bent at an angle so it touches the top of
the tank when installed.
6. Drill a 5/32” hole in line with your throttle arm.
It may be necessary to make an offset bend in
the throttle rod to make it align with the arm.
Screw the nylon snap link on the pushrod.
insert pushrod in the nylon tube and install in
the hole you drilled.
