11 Installer Guide
No. Installer Setting Factory Setting Comments
( Notes follow this table) Default Options (More information follows this table)
10 1st Stage Fan Control HG FAN 1 HG FAN 1 Select for 1st stage Gas heating
[note 3] HE FAN 1 Select for 1st stage Electric heating
11 Emergency Heat] HE EMER HE EMER Select for Electric Emergency Heat
Fan Control [note 4] HG EMER Select for Gas Emergency Heat
12 Reversing Valve REVO REVO Select for cool active Reversing Valve (O terminal)
(O/B Terminal) [note 5] REVB Select for heat active Reversing Valve (B terminal)
13 Fossil Fuel AE AUX AE AUX Select for Electric Auxiliary heat (with compressor)
Backup Heat [note 4] AG AUX Select for Gas Auxiliary heat (without compressor)
14 Compressor Power Outage oF CPOP oF CPOP Disables Power Outage Lockout Delay
Protection [notes 4, 6] on CPOP Enables Power Outage Lockout Delay
15 AC Power Interrupt AC oF MONR AC oF MONR Disables AC Power Interrupt Warning
Warning [note 6] AC on MONR Enables AC Power Interrupt Warning
16 Compressor Short 5 CSCP 5, 4, 3, 2 or Select a compressor short cycle protection delay of 5,
Cycle Protection [note 7] 0 CSCP 4, 3, 2 or 0 minutes
17 Residual Cooling 60 FAN 90, 60, 30 Select a Residual Cooling Fan Delay of 90, 60,
Fan Delay [note 7] or 0 FAN 30 or 0 seconds.
18 Adaptive Recovery oF REC oF REC Disables Adaptive (early) Recovery mode
Mode (ARM™) [note 8] on REC Enables Adaptive (early) Recovery mode
19 Indoor Remote Sensor I SENS I SENS Temperature is sensed from thermostat only.
Control* [note 9] E SENS Temperature is sensed from remote sensor only.
A SENS Temperature is combined with the thermostat and
the remote sensor.
20 Lockout Security Level 2 LOCK 2 LOCK If locked – Complete lockout is enabled
1 LOCK If locked – Partial lockout is enabled (SpeedBar ® is
still functional)
21 Auto Changeover 3 BAND 2, 3, 4 or 5 Select a Dead Band of 2°, 3°, 4° or 5˚ F
Dead Band [note 10] BAND (1°, 2° or 3° C) for Auto Changeover mode.
22 Compressor Balance NO BALC NO BALC Disables Balance Points
Point [notes 4, 11] 15-50 BALC Select a Compressor Balance Point of 15°- 50°F
(-9°-10° C)
23 Auxiliary Heat Balance NO BALA NO BALA Disables Balance Points
Point [notes 4, 11] 70-40 BALA Select a Auxiliary Heat Balance Point of 70°- 40° F
(21°- 4° C)
24 Heat Set Point Upper Limit 90LIM 90-60 LIM Select a Heat Set Point Upper Limit of 90°-60° F (32°-10° C)
25 Cool Set Point Lower Limit 45LIM 45-80 LIM Select a Cool Set Point Lower Limit of 45°-80° F (7°-27° C)
[note 7]
*When a Braeburn ® outdoor sensor is connected, the thermostat automatically recognizes it. Press PROG and HOLD at the same
time to display outdoor temperature.
NOTE: Additional options such as Service Monitors, setting the lock code, etc. are located in the User Settings –
See User manual for information on setting these options.
