Programming Installer Settings
cont.
Press the NEXT and buttons at the same time to enter Installer Mode.
Factory
Installer Options Default Options Comment
1 Temperature Scale oe 6 F oe 6 F, oe 6 C Selects either Fahrenheit
or Celsius.
2 Auto Changeover au oO au oO , Either enables or disables
au oOFf Auto Changeover.
3 System Type iiC ii C, 22 C, Selects single stage conventional,
ii HP, 22 HP, 2 stage conventional, single stage
32 HP heat pump, 2 stage heat pump
or 3 stage heat pump.
4 First Stage iH6 iH6, iHE, Not available with a heat pump
Fan Control system. Selects between 1st stage
gas or electric heat.
5 Aux Stage Control 2HE 2HE, iH6 Only available with multi-stage heat
pump system. Selects multi-stage
gas or electric heat.
6 Fossil Fuel auhAE auhAE, Only available with a multi-stage
Backup Option auhA6 heat pump system. Locks out 1st
stage during 2nd stage heat call
for fossil fuel backup system
(AUXAG). With an electric backup
system (AUXAE), both stages will run.
7 AC Power off-AC off-AC, Only available when thermostat is
Interrupt Warning o -AC installed as a hardwired unit. Select
between turning the AC power
interrupt warning off or on.
8 Compressor cpop OF cpopOF, Only available with multi-stage
Power Outage cpopO heat pump and AC power connected.
Select between compressor lock
off and compressor lock on.
9 Short Cycle cscp 5 cscp 5, cscp 4 Selects 5, 4, 3, 2 or 0 minutes for
Protection cscp 3, cscp 2 compressor short cycle protection.
cscp 0
10 Residual Cooling fa 60 fa 00, fa 30, Selects 0, 30, 60 or 90 seconds
Fan Delay fa 60, fa 90, as the time the fan will stay on
after the cooling system has
satisfied the set point temperature
and turned off the compressor.
11 Recirculating ci c0F ci c0F, ci c0 , Selects between Recirculating
Fan Lock Fan Lock off or on.
12 Set Sensor se s i se si, Only available if external sensor is
Control se sE, installed. Selects between Internal
se sA (I), External (E) and Averaging (A)
control of Internal (thermostat) and
External (remote indoor sensor) for
temperature control. Attaching an
outdoor sensor for outdoor
temperature display or balance
point control is automatically
detected. Test outdoor sensor
connection by pressing BACK and
NEXT at the same time.
13 Set Security Level sec 2 sec i, Selects between level 1 or level 2
for Keypad Lock sec 2 keypad lockout.
14 Dead Band a 3 a 2, Selects Auto Changeover Dead
a 3, Band of 2, 3, 4, 5˚ F (1.0, 1.5, 2.0,
a 4, 2.5˚ C). Only available if Auto
a 5 Changeover is enabled in option 2.
IMPORTANT:
At installation, Remote
Indoor Sensor must be
at room temperature.
u
u
u
u u
u
u
u
u
u
u
u
u
u
u
5
4
Programming Installer Settings
cont.
Status After RESET–Factory Default Settings
When the User RESET button is pressed, the following options will reset to the
factory defaults. All other settings are not changed when the RESET button
is pressed.
Function Status After RESET
Temperature Heat - 62° F, Cool - 83° F.
1st stage differential 0.2° F (0.1° C)
2nd stage differential 2° F (1.0° C)
3rd stage differential 2° F (1.0° C)
Filter, UV and Humidity Pad 0 days-No Warning, Timer reset
Check Monitor
Short Cycle Timer
Reset
Recirculating Fan Timer reset, 24 minute off cycle. With recirculating
lock set to ON (See Installer Settings), fan state
defaults to CIRC.
Setting Thermostat Installer Options
The Installer Options section allows the system and programming parameters
to be set up at installation. The Installer Options mode is menu driven. As the
different options are programmed, unnecessary options will be eliminated. For
example, if the system is set to single stage heat pump, Option 5, selecting
the AUX stage fan control will no longer be available.
The Installer Option mode is entered by holding the
NEXT and buttons together
for 3 seconds. Installer Option 1 (Temperature Scale) will be displayed. Press-
ing the or buttons will scroll between choices. To scroll to the next installer
option, press the
NEXT button. To scroll backwards between installer options,
press the BACK button. The thermostat will return to normal operating mode
by pressing the NEXT and BACK buttons at the same time.
NOTE: The thermostat will return to normal operating mode automat ically
after 30 seconds if no buttons are pressed.
NOTE: Any changes to Installer Option 3 (System Type) will cause Options 4, 5
and 6 to reset to the default values that are dependent on system selection.
