How to set Pass / Fail Conditions?
• Select Objects
• Select Pass Fail
Database Handling
• There are different ways to create or change the database
• Right mouse click to create Pass / Fail Conditions
g Empty Pass / Fail template will appear
g Name Pass / Fail by pressing “Save As” button
g Select a Criterion
g Type in Fail Values
Pass / Fail Results are shown as:
• P/F dots in database listing
• RED marked values in analysis tables
• Pass / Fail Result table
Edit Functions
• Menu Data
g Edit tab
g Comment, allows to put in comments after data transfer. These
comments will be displayed in the comment field of the printout
g
Remark, allows putting in remarks – text boxes for additional
information, which appear in the chart area.
