temp-gard Operation Main Menu
Start / Stop Start / Stop a measurement
Temperature Profile Display of temperature curve
Actual values Displays the actual temperature data of the
connected probes
Setup Definition of measurement and instrument
parameters
Setup Menu
Measurement Parameters Set number of probes
Set measurement time
Set trigger for measurement start
Set measurement interval
Define temperature units (°C / °F)
Instrument Select display time
Enter time / date
Select language
Info (Serial No. – Version)
Quick Start with temp-gard logger
• Define the measurement and instrument parameters in the
“Setup menu”.
• Go back to Main Menu and start measurement with Start/Stop
• LED will blink green g logger is active. Temperature data will be
saved based on trigger and interval settings!
Temperature Probe Connections
USB Port 2
USB Port 1
Enter Button 8 Switch on
Select function
Start / Stop a measurement
esc Button Always takes you one level up
UP / Down Button s t Navigation
USB Port 1 Transfer via cable
USB Port 2 Transfer via USB-Stick
Note:
When the temp-gard logger is switched on the status of the setup settings
will be displayed.
