ENGLISH
3
How to transfer data to temp-chart?
• Switch on the temp-gard logger
• Connect USB-Stick to temp-gard logger
• Data will be automatically saved on the USB-Stick
1. Empty USB-Stick
g Measurement data is saved on USB-Stick and remain on logger
2. USB-Stick with Organizer Files
g The selection menu “Configuration Files” will appear
− No configuration g organizer & measurement data remain in
logger, data is saved on USB-Stick
− Organizer xxx g measurement data is saved on USB-Stick
organizer & data are deleted in logger g new organizer is
transferred to logger
• Remove stick from logger and connect to PC
• Select menu “Instrument” in temp-chart
• Select SRAM/USB Stick
• Select “Transfer Data”
• Select file to be transferred g Organizer name will be offered as
file name (changeable)
• Close g Measuring Curve will be displayed
How to set Oven Start?
• Data Menu
g Set Oven Start
A vertical line appears which can be fixed on the real start point.
Confirm or Modify “General Information” and Sensors
