ENGLISH
4
How to Set a Tolerance Curve?
• Select Objects
How to Set Oven Specifications?
• Select Objects
• Select Tolerance Curves
Right mouse click to create new tolerance curve
g
A blank tolerance curve template will appear
g Name tolerance curve by pressing “Save As” button
g Enter tolerance settings
• Select Oven Specifications
Right mouse click to create new oven specifications
g
A blank oven specifications template will appear
g Name oven specifications by pressing “Save As” button
g Enter the oven specifications
• Save
• Save
The set oven specifications will be displayed on the graph, if they are
selected in View menu
