Chapter 3 OPERATION/MAINTENANCE
59
Removal
WARNING
THE LAMP IS EXTREMELY HOT AND CAN CAUSE SEVERE
BURNS! THE UNIT SHOULD BE TURNED OFF FOR AT LEAST 20
MINUTES BEFORE ATTEMPTING TO REPLACE THE LAMP.
1 Disconnect all power from Sensor. Turn Power switch
off and unplug power cord located on the back of the unit.
2
Turn the Sensor over (bottom up) and place on a soft flat
surface so as not to scratch the exterior surface.
3 Locate Lamp compartment door.
4
Open door by turning the screw fastener 1/4 turn counter-
clockwise.
5 Move the door out of position (Door may be hot if lamp
has been on for an extended time).
6 Locate the wire spring which retains the lamp in operating
position (Figure 3-4).
7 Gently depress the looped end of the wire spring and
release it from under end of the stationary post (doing this
will allow the lamp to move freely).
