Chapter 2 - Specifications
2-3
•
mV/V 4 digits to the right of the decimal
Optional Equipment
1756 RTA (Remote
Termination
Assembly
Hardy Part # -RTA (HI-1756-XX-RTA if ordered sep-
arately) Remote Termination supports two (2) sepa-
rate HI 1756-WS weigh scale modules or one (1) HI
1756-2WS weigh scale module. Unit includes DIN
rail mounting for 35mm x 15mm DIN rail.
RTA Cable
Assemblies
Hardy Part # -C6 (HI 1756-XX-C6)
•
Cable Length: 6 ft. (1.525 meters) from
the single channel module to the RTA.
Hardy Part # -C6 (HI 1756-XX-DC6)
•
Cable Length: 6 ft. (1.525 meters) from
the dual channel module to the RTA.
HI 215IT Series
Junction Box
NEMA rated waterproof enclosure which sums from
one to four load sensors load sensors.
•
-PS1 NEMA 4 Painted Steel
•
-SS1 NEMA 4X Stainless Steel
•
-FG1 NEMA 4X Fiberglass
Default Parameters
Parameter
Default
Setting
ChanActive
1
On
calyear*
calmonth*
calday*
calid[2]*
Calib Type
tareweight
0.0 lbs
Table 2-1: Default Parameters
