HI 1769-WS/HI 1769-2WS WEIGH SCALE MODULE
2-4
EMI Suppression Core
Cable Diameter
.250 inches Max. (6.4 mm Max)
Supression
Frequencies
Up to 500 MHz
Cable Types
•
Multi-strand
•
Single Conductor
Physical
Dimensions
Width - .705 inches (17.9 mm)
Height - .724 inches (18.39 mm)
Length - 1.272 inches (32.3 mm)
ZeroTrackEnable
False
0
ZeroTolerance
10.0 lbs
10.0
AutoZeroTolerance
10.0 lbs
10.0
MotionTolerance
5.0 lbs
5.0
Parameter
Default
Setting
Table 2-1: Default Parameters
