Chapter 2 - Specifications
2-3
Optional Equipment
1756 RTA (Remote
Termination
Assembly
Hardy Part # -RTA (HI-1769-XX-RTA if ordered sep-
arately) Remote Termination supports two (2) sepa-
rate HI 1769-WS or HI 1769-2WS weigh scale
modules. Unit includes DIN rail mounting for 35mm
x 15mm DIN rail.
RTA Cable
Assemblies
Hardy Part # -C6 (HI 1769-XX-C6)
•
Cable Length: 6 ft. (1.525 meters) from
the single channel module to the RTA.
Hardy Part # - D8 (HI 1769-XX-DC6)
•
Cable Length: 6 Ft. (1.525 meters) from
2 single or one dual module to the RTA.
HI 215IT Series
Junction Box
NEMA rated waterproof enclosure which sums from
one to four load sensors load sensors.
•
-PS1 NEMA 4 Painted Steel
•
-SS1 NEMA 4X Stainless Steel
•
-FG1 NEMA 4X Fiberglass
Default Parameters
Parameter
Default
Setting
ChanActive
On
1
Calib Type
none
OXFFFF
Tareweight
0.0 lbs
0
Metric
lbs
0
WAVERSAVER
®
1 Hz
3
SpanWeight
10,000.00
10,000.00
CalLowWeight
0 lbs
0
Num Averages
10
10
ROC Timebase
10 sec
10
Table 2-1: Default Parameters
