CTM64 Version 4 - User's Guide

Page 5

We do not offer a suitable housing as the CTM64 is normally installed into the housing of the keyboard
or switch board. An external power supply (7-12VDC@min. 250mA) is required. It is included with the
CTM64 only within Germany. In other countries the external power supply has to be ordered
additionally by the local dealer if necessary.

We offer a suitable connector set for the CTM64 (25.00 Euro in Germany, i.e. about 30.00 US$). This
includes four 16 pin flat cables with 16 pin socket connectors (female) pressed to the cables at one end
(length about 50cm) and four 3 pin female connectors with assembled cables for the potentiometers
(length about 30cm, potentiometers are not included). We also offer a suitable power supply (mains
input: 90-240VAC with European type connector, output: 9V DC/800mA) with CE and VDE approval
(20.00 Euro in Germany, i.e. about 25.00US$).

Installation of the CTM64 requires some electrical/electronical knowledge by the user. Please leave the
installation of CTM64 to an expert if you are not familiar with electronics. We take back only CTM64
modules in the original state, i.e. without solder residues, without scratches and so on.
The counterpart to CTM64 (MTC64) that converts 64 succeeding note messages into 64 0/+5V signals
is planned for early in 2001. With suitable drivers relays, lamps or electromagnetic valves can be
controlled via MIDI.

Please pay attention to the warranty notes on page 1. Ignoring these notes causes warranty loss and
the right to return the goods.
