CTM64 Version 4 - User's Guide

Page 11

Mode (jumper 5)

Jumper 5 installed:

note mode (factory setting)

Jumper 5 removed:

program change mode

Note/program offset (jumper 8)

Jumper 8 installed:

offset = 0 (factory setting)

Jumper 8 removed:

offset=36 (in note mode), resp. 64 (in program mode)

Octave offset (jumper 6/7, working only in note mode )

Jumper 6 installed:

offset = - 12 semitones (minus one octave) (factory setting)

Jumper 6 removed:

offset = 0 (no transposition)

Jumper 7 installed:

offset = + 12 semitones (plus one octave) (factory setting)

Jumper 7 removed:

offset = 0 (no transposition)

If both jumpers are installed there is no transposition (+12-12 = 0).

Control LED (4)

The LED is used to display any MIDI out activity. After power on the LED is permanently on. As soon
as a MIDI out event occurs the LED turns off for a short time thus indicating MIDI activity.

Factory setting of the jumpers

In the factory all jumpers of JP5 are installed. This means: MIDI channel 1, note mode, offset = 0, no
transpose ( +12 - 12 = 0). The potentiometer connectors ST1...ST4 are equipped with jumpers too so
that the inputs are connected to GND (i.e. no function).
