CTM64 Version 4 - User's Guide
MTC64
The counterpart to CTM64 that converts 64 succeeding note messages into 64 0/+5V (TTL type)
signals is called MTC64 (MIDI To Contact/Gate). With suitable drivers it is possible to control relays,
lamps, electromagnets, electromagnetic valves, motors, dimmer packs or switch packs and so on via
MIDI. The ideal control unit for the MTC64 is the CTM64. Closing a contact connected to CTM64 (e.g.
buttons) leads to activate the corresponding element (e.g. lamp or electromagnet) via MTC64. It is also
possible to record the CTM64/MTC64 activities with a computer sequencer so that the complete course
of events can be recorded.
