Please use this product according to the working environment requirements.

4.5.2

Check the space for installing and strength of structures

Confirm whether there is enough space for installing this product and its members.

4.5.3

Check the structural strength

4.5.4

Setting of DIP switch

According to control protocol and pan/tilt address, set the DIP switch (refer to pan/tilt

parameter settings)

Note:

Prior to install the pan/tilt, see the parameters in “pan/tilt setting”,

firstly set the baut rate, control protocol and address of pan/tilt

4.5.5

Powered on self-check of pan/tilt

In order to ensure the normal running of pan/tilt at the mounting place, prior to install,

please firstly connect the system control line, video line, and power line of pan/tilt into the

relevant sockets (wiring mode strictly comply with the notes on system control line, video

line and power line) for powered-on self-check, the pan/tilt shall adopt the factory default

setting, after the self-check, fulfill the normal installing works.

4.5.6

Please keep all packing materials of pan/tilt

After the pan/tilt unpacked, please properly keep the original packing materials of pan/tilt.

If any problems found, the pan/tilt should be well packed with the original packing

materials to mail to the agent or return the factory.

4.6 Mounting mode

The integral high speed pan/tilt camera may be divided into both on-board and

wall-mounted types:
