COP-USA ASH56NVIR-36S User Manual
Page 27
23
DIP switch state
Dome
Address DIP-1 DIP-2 DIP-3 DIP-4 DIP-5 DIP-6 DIP-7 DIP-8 DIP-9 DIP-10
1
ON OFF OFF OFF
OFF
OFF
OFF
OFF OFF OFF
2 OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
3 ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
4 OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
5 ON OFF ON OFF
OFF
OFF
OFF
OFF OFF OFF
6 OFF ON ON OFF
OFF
OFF
OFF
OFF OFF OFF
7 ON
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
8 OFF OFF OFF ON OFF
OFF
OFF
OFF OFF OFF
9 ON OFF OFF ON OFF
OFF
OFF
OFF OFF OFF
10 OFF ON OFF ON OFF
OFF
OFF
OFF OFF OFF
11 ON ON OFF ON OFF
OFF
OFF
OFF OFF OFF
12 OFF
OFF
ON ON
OFF
OFF
OFF
OFF
OFF
OFF
13 ON OFF ON ON OFF
OFF
OFF
OFF OFF OFF
14 OFF ON ON ON OFF
OFF
OFF
OFF OFF OFF
15 ON ON ON ON OFF
OFF
OFF
OFF OFF OFF
16 OFF OFF OFF OFF
ON OFF
OFF
OFF OFF OFF
17 ON OFF OFF OFF
ON OFF
OFF
OFF OFF OFF
18 OFF ON OFF OFF
ON OFF
OFF
OFF OFF OFF
…
…
1023 ON ON ON ON ON ON ON ON ON ON
For example:
3.3 Setting of protocol and default baud rate
SW2 may set the pan/tilt communication protocol and baud rate. The DIP-4 to DIP-1 of
