S ystem setting
10
1 The system enters into the main menu by calling 95 preset or b y calling
9 preset twice within 3 seconds.
2 Tilt up/down joystick to SYSTEM SETTING , press OPEN to e-
nter submenu.
3 Tilt up/down joystick to DISPLAY SETUP , press OPEN to enter
display setup menu, May setting the content of the display setup as
follow:
DOME LAB EL OFF
OPEN DOME LABEL
OFF
ON when setting OFF ,
it means not to display dome label .when p OPEN
DOME LABEL
EXIT
The displaying information on the screen will change with the dome
rotation; Through the information on the screen, user can see current dome
inside temperature, magnif ication, display zone etc. When all the label are
displayed, the dome works as the following picture shows,:
(In th e picture 30 5 means pan angle, 45 means tilt angle. )
4 Taking display dome label as an example to explain the operation proc-
ess. Tilt up/down joystick to move cursor to , press
, there is a sign besides , the cursor is twi-
nkling besides , as left picture shows;
5 Joystick tilts up/down, setting number changes between ON/OFF, when
setting , it means to display dome label ;
ressing , the cursor
jump back in front of , means label setting is finished,
when moving the cursor to , it means exiting the menu setting.
Temperature label Dome label
Zone label
Direction label
Zoom magnificatio n label
Pres et se tting
4. 4 Display setup
DISPLAY SETUP
DOME LABEL OFF
PRESET LABEL OFF
ZOOM LABEL ON
ZONE LABEL OFF
DIRECTION LABEL ON
LABEL OFF
TIME LABEL ON
DATE LABEL ON
BACK
EXIT
TEMPERATURE
MAIN MENU
SYSTEM SETTING
CAMERA SETTING
FUNCTION SETTING
WINDOW BLANKING
ALARMS
EXIT
DOME LABEL
PRESET LABEL
ZOOM LABEL
ZONE LABEL
DIRECTION LABEL
TEMPERATURE LABEL
TIME LABEL
DATE LABEL
07/1 2/06
17:3 9:10 Date la bel
Time label
SYSTEM SETTING
EDIT DOME LABEL
INITIAL INFO
DISPLAY SETUP
MOTION
CLEAR
PASSWORD SETUP
CLOCK SETTING
DOME ADDRESS
BACK
EXIT
