Text mode
Original mode

MESURgauge Software

1. Identify a working com port, and select the ap-

propriate port in Gauge Port Settings.

2. Under Gauge Port Settings, change baud rate to

115,200.

2. Under Reading Request String change String to

Write to “n” (lowercase, no quotes). Uncheck the
CR box.

3. Check the box labeled Travel Data Combined

with Load Data. No changes are needed to the
default lines, fields, and delimiter.

4. Click APPLY after making any changes in the

Gauge Port Settings area.

3. Force gauge settings (refer to the gauge’s user’s guide)

1. Set to automatic output of every sample.

2. Disable Mitutoyo BCD output.

4. Test stand settings

1. Set the baud rate to 115,200.

2. Set the Control mode to Console.

5. The Gauge Settings tab and all other gauge-related functions
cannot be used while MESURgauge is connected to the ESM301. It
is intended for use only when connected to a Mark-10 force gauge
directly.
