MESURgauge Software
Pan
This allows the user to reposition the graph. Click on the
graph, move the mouse to the desired location, and release
the mouse button.
4.10 X- & Y-scale Settings
Auto-scale
lock
When in the locked position, the scale is in auto-scale
mode.
Auto-scale
Click to auto-scale the axis.
Scale & grid properties
Click to adjust various scale and grid properties. A pop-up
context menu provides access to these properties.
4.11 Plot Palette (upper right corner of the graph)
Several plot options are available by clicking on the Plot Palette
icon. A menu of options will appear as follows:
