User’s Guide
The menu items are provided for quick access and convenience to
some common functions. The AutoScale X and Y items are equiva-
lent to the “padlock” icon on the scale palette at the lower right of
the graph, described below.
4.9 Tools (under the graph)
View
Clicking on this button brings up the following six viewing
options:
Set a zoom window with adjustable x- and y-
dimensions for a specific part of the graph
Set a zoom window with adjustable x-dimension for
a specific part of the graph
Set a zoom window with adjustable y-dimension for
a specific part of the graph
View entire graph
Zoom out
Zoom in
