User’s Guide
Reading Number at Cursor
Reading number corresponding to the current position of
the cursor.
5.4 Graph Colors
The graph color selection functionality is the same as described in
the Acquisition tab.
5.5 Statistics
This frame displays statistical data for the test.
Maximum
The maximum load reading measured during the test.
Minimum
The minimum load reading measured during the test.
Average
The average (mean) of the readings. Note that in situations
where load fluctuates between positive and negative val-
ues, this function considers polarity, not the absolute values
(for example, the average of +5 and -5 is calculated as 0).
Area Under Curve
The average of the absolute values of the load readings
multiplied by the selected time interval.
The above statistics are based on the data range specified in the X-
scale Settings frame. This range defaults to the full range at com-
pletion of the test. This range can be modified by entering the de-
sired range in the Minimum and Maximum numeric boxes. Click the
CALCULATE button to calculate the statistics for the specified
range. The graph will automatically adjust to reflect the new range.
5.6 Table
The table functionality is the same as described in the Acquisition
tab.
5.7 RECALL
Opens a file dialog box prompting to recall a previously saved test
20
