Determines if a coating system complies with the IMO
performance standard for protective coatings.
New PA2
New 90/10
Helps determine if film thickness over a large area conforms to
user specified min/max levels.
Open
Selects a previously created batch or sub-batch name to open and
make current. If it contains measurements, on-screen statistics will
immediately reflect values calculated from this batch. The
calibration setting (i.e. Cal 2) associated with this batch is also
opened (pg.9).
A solid triangle is displayed to the right of the batch
name when sub-batches are present. Press to view sub-
batches. This also applies to the following Delete, View and Print
options.
current batch
current sub-batch
statistics
(see pg. 13)
current reading
# of sub-batches in
current batch
NOTE:
can be accumulated for them. Batch 2 contains the statistics for
B2s1 and B2s2.
The following user selectable display options are available:
Display (appears only if a batch is currently open)
When a batch is open, press Up to scroll through the
above display options.
Chart: A real-time x-y chart of batch or sub-batch readings.
Image: An image uploaded (synchronized) from PosiTector.net.
Notes:
Instructions or notes uploaded from PosiTector.net.
None: default screen showing statistics information when a
batch is open.
microns
B2
71.3 1.5
s=3
s3 n5
72.4
74 72
Shortcut:
W
W
W
x
↨
σ
↨
x
72
0.9
σ
# readings in current
sub-batch
