2-3-3. LCD Display Layout
Highlighted Text Denotes Blinking Cursor or Characters
2-4. Display during initialization
2-4-1. The initial display upon power up
The following display appears during power up.
2-4-2. Display during warm up period
The instrument requires a warm up period to ensure an accurate measurement. Normally, the
warm-up period is complete within 30 minutes this will vary room temperature and test temperature.
The following display occurs during warm up period.
2-4-3. Display after warm-up
The following display occurs after the instrument has stabilized. The instrument is now ready to
measure a sample.
1 0 / 3 0 / 1 2 0 9 : 5 0
D e n s i t y 0 . 9 9 8 5 g / c m ³
T e m p 2 0 . 0 0 ° C T e s t 0 1
P r e s s E N T E R t o P r i n t
C A N N O N
D 1 5 5 D e n s i t y M e t e r
V e r 2 . 0 0
1 0 / 3 0 / 1 2 0 9 : 2 9
1 0 / 3 0 / 1 2 0 9 : 3 0
E Q U I L I B R A T I N G
T a r g e t 2 0 . 0 ° C
< < P l e a s e W a i t > >
1 0 / 3 0 / 1 2 0 9 : 4 0
R e a d y t o T e s t 2 0 . 0 ° C
P l e a s e L o a d S a m p l e
P r e s s M E A S t o S t a r t
