3 Technical data
24 Multivapor™ Operation Manual, Version E
Table 3-8: Optional accessories (cont.)
Product Order number
F-100, 230 V; 50/60 Hz (400 W) 11056460
F-100, 115 V; 50/60 Hz (400 W) 11056461
F-108, 230 V; 50/60 Hz (800 W) 11056464
F-108, 115 V; 50/60 Hz (800 W) 11056465
3 .2 Materials used
Table 3-9: Materials used
Component Material designation
Housing Multivapor PUT foam
Heating plate Aluminium, anodized
Protective ring heating plate EPDM
Crystal rack Aluminium, borosilicate glass
Standard tube adapters PETP
PEEK tube adapters PEEK
Seals for tube adapters PTFE
Standard vacuum cover PETP
Alternative vacuum cover PEEK
Vacuum cover seal EPDM
O-ring for the vacuum cover adapter EPDM and FKM or FFKM (optional)
Vacuum tube Ribbed PFA with PTFE seals
Protective shield Polycarbonate
