10 Spare parts
58 R-210/215 Operation Manual, Version F
10 .1 Glass assembly A
Fig. 10.1: Glass assembly A
Table 10-1: Glass assemblies A
Product Order number Product Order number
Glass assembly A05 complete, with 1 l
receiving flask, without seal and vapor duct 48168 PTFE drain disk 40625
Diagonal condenser A 05 (23875+23900
+ Tube clips GL-14 complete) 46988 Stop cocks SJ 18.8/38 40627
Glass assembly A05 complete, P+G with
1 l coated receiving flask, without seal and
vapor duct 48169 PTFE tube 460 mm 00643
Diagonal condenser A 05 P+G (23875
+ 23900 + tube clips GL-14 complete) 47976 Set of tube clips straight GL-14,
4 pieces, 4 x olive straight with screw
caps 37642
Tube clips GL-14, bent, complete,
set of 4 37287 Set of tube clips GL-14, 4 x bent, 2 x
straight, 6 x screw caps 38000
Vapor duct long SJ 29/32 with Combi Clip 48164 Clip for receiving flask S35 03275
Gasket WD 26 (seal) 48021 Screw cap GL-10 23875
Flange screwed connection 48237 Cross sleeve 27344
PTFE tube, 600 mm 28096 Rubber band 32013
FPM-O ring 3×2.7 mm 23900
