3 Technical data
16 R-210/215 Operation Manual, Version F
Order number:
2 3 x x x Y x x x Glass assembly BY
• Vertical condenser with additional double
jacket for cooling
• Additional joint on the top of the condenser
for flexible expansion
• For particularly efficient condensation
• Evaporating flask feed via stop-cock
• Connection for vapor temperature sensor
Order number:
2 3 x x x x 1 x x P+G coating
If required, all glass parts can be plastic coated
NOTE
The broken flask shown on the picture on the
left demonstrates the function of the P+G
coating in case of glass breakage.
