Use this pair of diagrams to notate settings for the configurations you use frequently. Copy this page to plain
paper, enlarging if necessary, and mark DIP switch settings with a pen or marker.
RS–232/422
STEREO LINK
6416
Y2
B
A
ON
CTL
CLK
AUTO
ERR
1 2 3 4 5 6 7 8 9 10 11 12
Configuration:
Project Name:
Date:
