Page 45: Network mode a‑net transmit settings (manual mode)
DIP Switch Block 9 (SW9)
Switch Block SW9 controls network‑level functions and A‑Net transmit/receive settings.
DIP Switch Block 9 (SW9) Functions
Switch
Function Off (down)
Function On (up)
1
Auto Mode
Manual Mode
2
A‑Net Transmit Port (A, B, or A+B) Select 0 *
A‑Net Transmit Port (A, B, or A+B) Select 0
3
A‑Net Transmit Port (A, B, or A+B) Select 1
A‑Net Transmit Port (A, B, or A+B) Select 1
4
A‑Net Receive Port (A or B) Select *
A‑Net Receive Port (A or B) Select
5
Transmit Audio Base Slot Select 0 *
Transmit Audio Base Slot Select 0
6
Transmit Audio Base Slot Select 1
Transmit Audio Base Slot Select 1
7
Receive Audio Base Slot Select 0 *
Receive Audio Base Slot Select 0
8
Receive Audio Base Slot Select 1
Receive Audio Base Slot Select 1
9
Card settings controlled by onboard DIP
switches
Card settings controlled by Pro64 Network
Manager software
10
Not Managed
Managed Mode
* The tables that follow show DIP switch settings for transmit/receive.
Network Mode
The Pro64 network can be set to operate in either Auto Mode or Manual Mode using switch 1 in DIP Switch Block
SW9. The default setting is Auto Mode.
A-Net Transmit Settings (Manual Mode)
The 6416Y2 A‑Net Interface Card can transmit its activated channels to A‑Net Port A, B, or both A and B when the
network is running in Manual Mode. (This setting does not apply when the network is operating in Auto Mode.)
Use switches 2 and 3 to direct A‑Net data to a specific port.
A‑Net Transmit Settings
Port A
DIP Switch 2
DIP Switch 3
off
off
Port B
on
off
Ports A and B
off
on
Not supported
on
on
P
N
ote
:
Manual Mode is not supported by Pro64 Network Manager or when AllFrame devices are part of the
network.
