Specifications
Audio Inputs 16, balanced line‑level
TRS Inputs
(line level)
Tip: Audio +; Ring: Audio ‑; Sleeve: Ground
TRS Thru Impedance matched output
A/D Conversion 48kHz, 24‑bit
Gain Settings +22dBu, +4dBu, 0dBu, ‑10dBV
4‑position gain switch, per channel pair
Metering LEDs; green: Signal Present, red: Clip; per channel
Stereo Operation Stereo Link, per channel pair;
Two‑position switch (Normal, Link)
Maximum Input
Level
+22dBu
Input Impedance 17.8k ohms
Freq. Response 4Hz‑22kHz +0.2dB/‑3dB
THD +N < 0.003%
Crosstalk ‑90dB
Signal to Noise
(unweighted)
90dB typical, A/D to D/A
Measured from AN‑16/i to AN‑16/o Output Module
Bit Error Rate (BER) 10 ‑12
Digital Outputs A‑Net: 1; A‑Net Expansion: 1; RJ45 connector
Pro16 A-Net A‑Net Expansion combines two A‑Net streams (32
channels of audio) onto one Cat‑5e cable
uses unshielded Cat‑5e UTP (or better) cable
Latency <0.880 msec (measured from analog input to
analog output)
Power Supply
Input Voltage
Output Voltage
Plug Size
External, DC, universal switching type
100‑240 volts, 50/60Hz, 30VA
18‑24 VDC, 0.5 amp
2 mm
Dimensions 19” (482.6 mm) wide x 5.75” (146 mm) deep;
1U high
Weight 6.8 lb. (3.08 kg)
Options AN‑16SBR System Bridge; used to combine up
to four A‑Net streams for transmission over one
Cat‑5e cable
All Aviom products are designed and manufactured in the USA.
