39 AN-16/
i
i
Nput
M
odule
u
ser
G
uide
The following example shows a complex network that combines A‑Net from
two different networks, sending 32 channels from each location to a third
user.
AN-16/o
AN-16/i
AN-16/i
AN-16/o AN-16/i
AN-16/o
AN-16/o
AN-16/i
A-Net Out
A-Net Out
A-Net In
A
B
C
D
A
B
C
D
Bridge
AN-16/o
AN-16/i
AN-16/i
AN-16/o AN-16/i
AN-16/o
AN-16/o
AN-16/i
A-Net Out A-Net In
A
B
C
D
A
B
C
D
A
B
C
D
Bridge
Bridge
AN-16/o
AN-16/o
AN-16/o
AN-16/o
A-Net In
A
B
C
D
System Bridge System Bridge
System Bridge
System Bridge
System
Bridge
System Bridge
Data from two Pro16 networks is combined and distributed to a third location.
As with all A‑Net compatible devices, any available A‑Net Out can be used as
a starting point for expansion.
In the preceding diagrams, any Pro16 input module can be substituted for
the AN‑16/i modules. These include:
• AN‑16/i‑M ‑ 16 mic/line inputs
• Y1 card ‑ for use with Yamaha digital mixing consoles;
routes audio from the Yamaha interface to A‑Net
Digital
• console cards from third‑party manufacturers that
support Pro16 A‑Net
