25 AN-16/ i v .2 i Nput M odule u ser G uide
Line-level Devices
In addition to connecting a traditional mixing console, there are numerous other audio sources that can
be used with the AN-16/i v.2. There is no requirement that your audio sources be connected to a mixing
console first.
Using some creative patching, you’ll find numerous ways to get audio into a personal mixing or audio
distribution system. Here are a few examples:
Connect the stereo outputs of multiple • CD/DVD players to inputs on the AN-16/i v.2 Input
Module to distribute a variety of music programs to multiple rooms. No mixing console is
needed.
Patch a drum machine output or line output from a computer sound card or
• DAW into the
AN-16/i v.2 to provide a click track for musicians.
Connect multiple keyboards directly to the AN-16/i v.2. Then patch the
• Thru jacks on the
AN-16/i v.2 to the main mixing console inputs.
Connect outputs from stereo guitar processors or amp simulators.
•
Virtual drums can be connected directly into the AN-16/i v.2 Input Module before being •
connected to a mixing console.
Input Output Input Thru
AN-16/i v.2
Console Line
Input
Line-Level
Device
A line-level device is connected to the input module before being connected to the console’s line input.
Patching devices into the AN-16/i v.2 before they get plugged into the mixing console can save configurable
console outputs that may be needed for other purposes.
